Green Rotary Laser

Green Rotary Laser

This green rotary laser level is designed for small and medium-sized outdoor projects. It adopts 360° rotary scanning technology with green light source, which can form a uniform horizontal reference plane on the site. With a dedicated receiver, it can expand the working range, and is suitable for conventional construction and site leveling operations.
Send Inquiry

Product Introduction

Product Description



This green rotary laser level is designed for small and medium-sized outdoor projects. It adopts 360° rotary scanning technology with green light source, which can form a uniform horizontal reference plane on the site. With a dedicated receiver, it can expand the working range, and is suitable for conventional construction and site leveling operations.



It is equipped with a dual-axis automatic self-leveling system, which automatically levels after power-on. It can output references in both horizontal and vertical directions, and supports manual slope setting, which can meet the basic needs of road and site slope finding. The body adopts a high-strength engineering plastic shell + rubber anti-collision structure, with IP65 protection rating, which can resist dust, rain and accidental impact, and adapt to the wild environment of construction sites.



It is equipped with a remote control, which can switch modes and adjust slopes at the far end of the site without frequent trips to the instrument. It has a built-in lithium battery pack with a battery life of 6-8 hours in full-brightness mode, and also supports dry battery power supply to cope with wild scenarios without charging. The bottom is equipped with a 5/8-inch industrial-grade threaded interface, compatible with professional tripods and staff receivers.

product-800-800



Specifications





Parameter

Technical Specification

Laser Type

Green rotary laser

Laser Wavelength

532nm

Laser Class

Class Ⅱ

Scanning Mode

360° rotary scanning

Horizontal Accuracy

±1.5mm / 10m

Vertical Accuracy

±2mm / 10m

Self-Leveling Range

±5°

Self-Leveling Time

<5 seconds

Naked-Eye Visible Distance

20m

Slope Adjustment

Manually adjustable

Battery Specification

Large-capacity lithium battery pack

Battery Life

6-8 hours

Protection Rating

IP65 dust and water resistance

Operating Temperature

-10℃ ~ 50℃

Base Thread

5/8-inch industrial-grade interface

Net Weight

Approx. 1.8kg



product-800-800



Application Scenarios

It is suitable for small and medium-sized outdoor projects and indoor venue construction. In construction engineering, it can be used for factory foundation leveling, formwork calibration, and steel structure positioning; in municipal engineering, it can be used for road leveling, pipeline laying elevation, and slope protection calibration; in site finishing, it can be used for sports field leveling and small site leveling. It is also suitable for large-span indoor scenarios such as warehouse construction, venue ceiling installation, and curtain wall construction.



After-Sales Service


We have established a corresponding service system for engineering contractor customers, and assign dedicated contact persons for bulk procurement customers. During the order production process, the contact person will regularly synchronize the production progress, feedback the actual production line status, and arrange mid-term inspection and final inspection links. After the goods are delivered, we will provide customs clearance documents and track the logistics status. After the customer signs for receipt, we will conduct a batch delivery acceptance return visit. If there are product quality problems or transportation damage, the after-sales staff will follow up and handle them. All products come with a one-year warranty service. For quality problems caused by non-human damage during the warranty period, we can provide maintenance and parts replacement services.



Payment Terms


We have formulated payment terms for different order types. For conventional stock models, the settlement method is 30% advance payment and 70% balance paid before shipment; for customized development orders, the sample making and mold opening fee shall be paid first. After the sample is confirmed by the customer, 50% of the total order amount shall be paid as the production advance payment. After the mass production is completed and passes the final inspection, the remaining 50% balance shall be settled before shipment. For bulk procurement orders, tiered discounts can be provided according to the order volume. Currently, we support settlement in a variety of mainstream currencies, and all payment processes are subject to the formal Proforma Invoice (PI) confirmed by both parties.



Quality Control


Export orders adopt standard foreign trade protective packaging. The interior is buffered with pearl cotton and foam lining, and the outer layer is matched with thickened corrugated cartons, which can reduce the impact of bump and extrusion during long-distance transportation. We can adjust the packaging plan according to customer requirements, including customized brand color boxes, adding exclusive logos, and supporting multilingual manuals. Currently, we support EXW and FOB trade terms, and can assist customers with export services such as booking, customs declaration and container loading. The production cycle of standard orders of 1000-3000 units is 30-45 days, and the specific delivery time can be negotiated and adjusted according to the order volume.
