Green Rotary Laser Level

This rotary laser sweeper is oriented to the professional engineering market. It adopts a high-brightness green laser source with 360° rotary scanning technology, which can form a continuous and uniform horizontal reference plane in open sites. With a dedicated receiver, it can expand the working range, and is suitable for conventional engineering scenarios such as civil construction, municipal engineering, and landscaping.

It is equipped with a dual-axis magnetic damping automatic self-leveling system, which can automatically level in both horizontal and vertical directions. Calibration can be completed within ±5°, and sound and light alarm will be triggered automatically when exceeding the self-leveling range to ensure the reliability of the measurement reference. The instrument supports dual-axis manual slope adjustment, which can meet engineering needs such as road slope finding and site drainage slope setting.

The body adopts a fully enclosed rubber anti-collision frame, and the key optical window is equipped with protective glass, with IP54 protection rating, which can resist construction site dust, rain spray and accidental bumps. The device is equipped with a wireless remote control as standard. Construction personnel can switch the rotating speed and adjust slope parameters at the far end of the site without frequent trips to the instrument position. The rotating speed supports multi-level adjustment, and the scanning angle can be set to multi-segment mode, taking into account both reference line setting and local positioning needs. It is equipped with a rechargeable battery pack with a battery life of 6-8 hours in full-brightness mode, and is also compatible with ordinary dry battery power supply, which is more flexible for wild scenarios without charging. The bottom is equipped with a standard 5/8-inch industrial-grade threaded interface, which can be adapted to professional surveying tripods and receiver sets.
